TYPE FESD
Smooth Bore FEP Lined Hose
Applications:
Mainly used in the demanding pharmaceutical industry, it can also be applied to industries such as aerospace, photovoltaics, electronic, and semiconductors. Suitable for suction and delivery of various chemical media.
Features:
High cleanliness, high chemical stability, excellent temperature resistance, high airtightness, and wear resistance.
Construction:
Inner tube: High purity FEP inner layer.
Reinforcement: Double layer high-strength fiber weaving and spiral steel wire.
Cover: Blue EPDM, antioxidant, wear-resistant.
Temperature range: -40℃ to +150℃ (Depending on the medium).
Standard/Approval: FDA 21 CFR 177.1550, USP Class VI, GB4806.7, GB31604.30
|
Part No. |
ID |
OD |
Bending Radius |
Working Pressure |
Vacuum |
Standard Length |
||
|
inch |
mm |
mm |
mm |
psi |
bar |
bar |
m |
|
|
FESD019 |
3/4" |
19 |
31 |
100 |
240 |
16 |
0.9 |
20 |
|
FESD025 |
1" |
25.4 |
38 |
140 |
240 |
16 |
0.9 |
20 |
|
FESD032 |
1-1/4" |
31.8 |
44 |
180 |
240 |
16 |
0.9 |
20 |
|
FESD038 |
1-1/2" |
38 |
51 |
230 |
240 |
16 |
0.9 |
20 |
|
FESD051 |
2" |
50.8 |
65 |
290 |
240 |
16 |
0.9 |
20 |
